Enverge 1860 CDN spray-applied polyurethane foam is a CAN/ULC S705.1-15 compliant spray-applied, two component, closed cell insulation system. The product is formed by the reaction of proprietary resin blend and polymeric methylene diphenyl diisocyanate. The resin blend is comprised of polyols, additives, fire retardants and low global warming potential blowing agents. Enverge 1860 CDN is light green in colour. The spray applied nature of Enverge 1860 CDN spray foam allows the material to seal cracks and voids, expanding to form a monolithic structure with high thermal performance (resistance to heat flow). Enverge 1860 CDN spray foam can form various control layers for buildings and structures: insulation, air barrier, moisture retarder and weather barrier. Enverge 1860 CDN is manufactured under a quality control program administered under the auspices of ISO 17025. 1860 CDN must be installed in accordance with CAN/ULC-S705.2.
Enverge 1860 CDN
2.17 lb.
Core Density
1.87
LTTR
5.45
R-Value Per Inch
Key Features
Listed by the Canadian Construction Materials Centre (CCMC) under evaluation listing #14087-L.
LTTR - TYPE 1 provides long-term thermal resistance of 1.87 m²•K/W at 50 mm.
Gaco OnePass 1880 medium-density SPF has an R-Value of 5.45 per inch.
Use on substrates as cold as -10°C (14°F).
May be used in interior, exterior, or subterranean applications.
Is dimensionally stable and will not shrink or expand.
Typical Applications
Residential, commercial, industrial and institutional building insulation.
Interior perimeter stud wall insulation.
Exterior, below grade and under slab applications.
Freezers & Coolers.
Spray Equipment
This product is designed to be sprayed with a plural component spray machine. If you’re thinking about getting into spray foam insulation, do it right. Graco’s complete line of Reactor equipment gives you the reliable performance your company demands. Don’t settle for anything less.
MSDS & Spec Sheets
Please click the links below for detailed information on the Enverge 1860 CDN material.
