Reactor 2 E-30

Reactor 2 E-30

Each feature in the Reactor 2 E-30 was strategically designed to help your business, with innovations that help your operation run smoothly. Software and hardware enhancements for better spray performance. New technologies that add to your bottom line.

Compact footprint – more room in your spray rig

Easy to operate Advanced Display Module interface

Graco InSite – Remote Reporting Technology (Included on Elite models)

Better spraying performance compared to traditional electric Reactor systems

Quick Specs

2000 psi

Max Pressure

310 ft (94 m)

Max Hose Length

190°F (88°C)

Max Fluid Temp

10.2 or 15.3

kW Heaters

30 lb (14 kg)

Max Output/min

Electric

Proportioner

Features

Detailed Specs

Maximum Fluid Working Pressure
2000 psi (138 bar, 13.8 MPa)

Minimum Fluid Working Pressure
N/A

Primary Heater Power
10.2 or 15.3 kW

Maximum Fluid Temperature
190° F (88° C)

Maximum Output
30 lb (13.6 kg)/min

Output Per Cycle (A and B)
0.0272 Gallon (0.1029 Liter)

Amperage Requirement 10.2 kW
230V (Single Phase) 78 Amps
230V (Three Phase) 50 Amps
400V (Three Phase) 34 Amps

Amperage Requirement 15.3 kW
230V (Single Phase) 100 Amps
230V (Three Phase) 62 Amps
400V (Three Phase) 35 Amps

Line Voltage Options
230V units: 195–264 Vac, 50/60 Hz
400V units: 338–457 Vac, 50/60 Hz

Weight
355 lb (161 kg)

Fluid Inlets
3/4 npt(f), 300 psi maximum

Fluid Outlets
Component A (ISO)
#8 1/2 in. JIC, with #5 5/16 in. JIC adapter
Component B (RES)
#10 5/8 in. JIC, with #6 3/8 in. JIC adapter

Fluid Circulation Ports
1/4 npsm(m) 250 psi

Sound Power, per ISO 9614–2
87.3 dB(A)

Sound Pressure, 1 m From Equipment
93.7 dB(A)

Parts and Supplies

Our online store has a large selection of spray equipment, parts and supplies ready to ship.

Adobe Acrobat Reader is required to view the above PDF files. This is a free program available from the Adobe web site. Follow the download directions on the Adobe web site to get your copy of Adobe Acrobat Reader.

Spray Rigs

The Graco Reactor 2 E-30 is also available in the following turn-key spray rigs. We build a full line of spray rig configurations in addition to our ability to provide a limitless set of customization’s. Each of our spray rigs are a true turn-key, sustained, and custom tailored solution for your application.

PREDATOR Rig

Predator Spray Rig

BOXER Rig

Boxer Spray Rig
