Reactor E-20

Reactor E-20

Graco’s Reactor E-20 is now upgraded with leading technology based on the H-series platform. The advanced features are designed to provide longer life, less downtime and Graco reliability – and add great value to any proportioning equipment line-up.

Powerful hybrid heaters for better temperature control

Longer-lasting modular heater control boards that minimize downtime

Quick knockdown lower pumps for easy maintenance

Durability you’ve come to expect

Quick Specs

2000 psi

Max Pressure

210 ft (64 m)

Max Hose Length

190°F (88°C)

Max Fluid Temp

6.0

kW Heaters

20 lb (9 kg)

Max Output/min

Electric

Proportioner

Features

Detailed Specs

Maximum Fluid Working Pressure
2000 psi (138 bar, 13.8 MPa)

Minimum Fluid Working Pressure
N/A

Primary Heater Power
6.0 kW

Maximum Fluid Temperature
190° F (88° C)

Maximum Output
20 lb (9 kg)/min

Output Per Cycle (A and B)
0.0104 Gallon (0.0393 Liter)

Amperage Requirement
230V (Single Phase) 48 Amps
230V (Three Phase) 32 Amps
400V (Three Phase) 24 Amps

Line Voltage Options
230V units: 195–264 Vac, 50/60 Hz
400V units: 338–457 Vac, 50/60 Hz

Weight
342 lb (155 kg)

Fluid Inlets
3/4 npt(f), 300 psi maximum

Fluid Outlets
Component A (ISO)
#8 1/2 in. JIC, with #5 5/16 in. JIC adapter
Component B (RES)
#10 5/8 in. JIC, with #6 3/8 in. JIC adapter

Fluid Circulation Ports
1/4 npsm(m) 250 psi

Sound Power, per ISO 9614–2
80.0 dB(A)

Sound Pressure, 1 m From Equipment
70.2 dB(A)

Parts and Supplies

Our online store has a large selection of spray equipment, parts and supplies ready to ship.

Adobe Acrobat Reader is required to view the above PDF files. This is a free program available from the Adobe web site. Follow the download directions on the Adobe web site to get your copy of Adobe Acrobat Reader.

Spray Rigs

The Graco Reactor E-20 is also available in the following turn-key spray rigs. We build a full line of spray rig configurations in addition to our ability to provide a limitless set of customization’s. Each of our spray rigs are a true turn-key, sustained, and custom tailored solution for your application.

PROLIGHT Rig
